Technical Specifications
|
|
|||||
|---|---|---|---|---|---|
|
Model Based on Size
|
5'-6'
|
7'
|
9'
|
10'
|
12'
|
|
Height Of Centre
|
10/12/14/15/18 Inch
|
10/12/14/15/18 Inch
|
10/12/14/15/18 Inch
|
10/12/14/15/18 Inch
|
10/12/14/15/18 Inch
|
|
Width Of Bed
|
13/15/18 Inch
|
13/15/18 Inch
|
13/15/18 Inch
|
13/15/18 Inch
|
13/15/18 Inch
|
|
Admit Between Centre
|
555mm
|
965mm
|
1575mm
|
1930mm
|
2515mm
|
|
Swing Over Cross Slide
|
11.5 to 24.5 Inch
|
11.5 to 24.5 Inch
|
11.5 to 24.5 Inch
|
11.5 to 24.5 Inch
|
11.5 to 24.5 Inch
|
|
Swing Over Bed
|
20/24/28/30/36 Inch
|
20/24/28/30/36 Inch
|
20/24/28/30/36 Inch
|
20/24/28/30/36 Inch
|
20/24/28/30/36 Inch
|
|
Spindle Bore
|
51/80/100/125 mm
|
51/80/100/125 mm
|
51/80/100/125 mm
|
51/80/100/125 mm
|
51/80/100/125 mm
|
|
Spindle Speed No
|
8
|
8
|
8
|
8
|
8
|
|
Threading Range
|
2 to 24 TPI
|
2 to 24 TPI
|
2 to 24 TPI
|
2 to 24 TPI
|
2 to 24 TPI
|
|
Threading Range
|
1 to 6 mm
|
1 to 6 mm
|
1 to 6 mm
|
1 to 6 mm
|
1 to 6 mm
|
|
Required(H.P)
|
2 H.P
|
3 H.P
|
3 H.P
|
3 H.P
|
3 H.P
|
|
Lead Screw
|
38.1 x 4 TPI
|
38.1 x 4 TPI
|
38.1 x 4 TPI
|
38.1 x 4 TPI
|
38.1 x 4 TPI
|
