Vertical Bandsaw Machine
Vertical Bandsaw Machine
Sudershan Machinery manufactures a wide rangeg of high-performance vertical bandsaw machines with advanced engineering, quality checks, and cost-effective production, ensuring precision, durability, and customer satisfaction.
- Superior build quality made with high grade materials.
- Equipped with energy-saving motors and systems to reduce operational costs.
- Offers top-notch machines at cost-effective rates without compromising on quality.
Technical Specifications
|
|
||||||
|---|---|---|---|---|---|---|
|
Model No.
|
SMVB18
|
SMVB24
|
SMVB30
|
SMVB36
|
SMVB32
|
SMVB42
|
|
Wheel Diameter
|
18 inches / 455mm
|
24 inches / 605mm
|
30 inches / 760mm
|
36 inches / 910mm
|
32 inches / 990mm
|
42 inches / 1070mm
|
|
To Cut Max. Diameter
|
12 inches / 300 mm
|
15 inches / 380mm
|
21 inches / 535mm
|
27 inches / 685mm
|
29 inches / 735mm
|
33 inches / 835mm
|
|
Wheelface
|
2 inches / 50mm
|
2 inches / 50mm
|
2.5 inches / 63mm
|
3 inches / 75mm
|
3 inches / 75mm
|
3 inches / 75mm
|
|
Diameter Of Spokes
|
16mm
|
20mm
|
20mm
|
22mm
|
22mm
|
22mm
|
|
Speed RPM
|
800
|
750
|
700
|
650
|
625
|
550
|
|
Maximum Length of Blade
|
11 ft
|
14 ft
|
18 ft
|
20 ft
|
22 ft
|
24 ft
|
|
Pulley Size
|
8 inches (v-belt) / 200mm
|
10 inches (v-belt) / 250mm
|
10 x 3 inches / 250 x 75mm
|
12 x 4 inches / 300x 100 mm
|
12 x 4 inches / 300 x 100 mm
|
12 x 4 inches / 300 x 100 mm
|
|
Power Required
|
2 hp
|
5 hp
|
7.5 hp
|
10 hp
|
10 hp
|
15 hp
|
|
Power Required
|
2 hp
|
5 hp
|
7.5 hp
|
10 hp
|
10 hp
|
15 hp
|
|
Table size
|
"18 x 20 inches / 455 x 505 mm"
|
"27 x 28 inches / 685 x 710 mm"
|
"30 x 34 inches / 760 x 860 mm"
|
"39 x 42 inches / 985 x 1070 mm"
|
"39 x 42 inches / 985 x 1070 mm"
|
"39 x 42 inches / 985 x 1070 mm"
|
Cutting Capability of vertical bandsaw machine
- Can perform intricate cuts, including curves and angles.
- Allows creative or detailed work where precision shaping is needed.
Machine Orientation & Applications
- The blade is positioned vertically.
- Material is manually or automatically fed into the blade, which remains stationary.
- Ideal for freehand and detailed cuts, as the operator has more control over the cutting angle.
- Used for cutting irregular shapes, contour cutting, profiling, and trimming.
- Suitable for wood, plastics, and small-scale metalworking.
